Chesapeake Bay Bridge-Tunnel

If you plan to travel down Virginia's Eastern Shore to get to the beach this summer, you might drive over the Chesapeake Bay Bridge-Tunnel. As its name implies, the structure functions as both a bridge and a tunnel.

After the $200 million structure's completion in 1964, the American Society of Civil Engineers named it "one of the seven engineering wonders of the modern world."

To construct it, workers dug huge underwater ditches for two tunnels and lined them with rocks. They then lowered plugged-up pieces of the concrete tunnel into the ditches. To allow cars to drive through, the workers then unplugged the tunnel pieces.

Functional Engineering Marvel

The tunnels run about a mile under the bay, allowing ships and boats to travel over them, according to The Washington Post. The tunnels connect to the bridge sections via four manmade islands that are each as large as a football field. The depth of the water ranges from 25 to 100 feet, according to the Chesapeake Bay Bridge and Tunnel Commission.

Construction of the Chesapeake Bay Bridge-Tunnel, early 1960s. Image Source: Chesapeake Bay Bridge and Tunnel Commission

Before the structure was built, 50 to 60 cars at a time would drive up onto ferries, which would carry them across the water, with the Chesapeake Bay to the west and the Atlantic Ocean to the east.

The 23-mile Chesapeake Bay Bridge-Tunnel included only one northbound and one southbound lane until 1999, when one more lane was added in each direction. Over 100 million cars and trucks have driven on the bridge-tunnel since 1964.

Construction of a $755 million parallel tunnel that would help alleviate traffic is expected to begin in fall 2017 and be completed by 2022. Called the Thimble Shoal Channel, it would connect to the Chesapeake Bay Bridge-Tunnel's existing roadway.
